Customizable content

Air pump: flow rate: 0.2-90L/min, maximum pressure: 0.5-12bar, voltage: DC1.5-24V, optional
Water Pump: flow rate: 0.2-5L/min, maximum pressure: 4-30bar, voltage: DC3V-24V, optional
Vacuum pump: flow rate: 0.2-70L/min, maximum negative pressure: 30-98kPa, voltage: DC1.5V-24V, optional

Model	Ultimate vacuum kPa	Flow L/min	Max. Pressure Bar	Power W	DC motor V	Dimensions mm	Weight g
T4V12A75R60	75	20*2	3	25	6/9/12/24	110/83/41	360
T4V12B75R55	70	16*2	2.5	20	6/9/12/24	110/83/41	360
T4V12C75R37	65	10*2	2	15	6/9/12/24	110/91/45	360
T4V12A75R29	75	8*2	2	10	6/9/12/24	110/91/45	360

product

They are available with options for application requirements related to size, motor, control, voltage, chemical resistance, safety, vibration, noise and temperature resistance. All pump types offer oil-free operation.

Product Features

Optimized pump body to ensure small volume, provide large flow and maintain relatively low power consumption. The gas flow is stable and the motor runs in a wide range.

- High performance

- Dc brushed motor with 2000hours lifetime

- Dc brushless motor with >10000hours

- Imported ball bearing material design

- Professional seal design ensures low leakage rate

- Pollution-free sample gas

- High quality imported EPDM and PTFE/FKM

- Rubber materials, withstand a variety of gas corrosion

Miniature pumps power portable cleaning devices, enabling precise liquid transfer in applications like handheld sprayers (disinfectants, detergents), carpet extractors, window vacuums, and pressure washer systems. Their compact size, chemical resistance, and efficient fluid handling enhance portability, reduce waste, and support labor-saving automation in professional and household cleaning.
