Customizable content

Air pump: flow rate: 0.2-90L/min, maximum pressure: 0.5-12bar, voltage: DC1.5-24V, optional
Water Pump: flow rate: 0.2-5L/min, maximum pressure: 4-30bar, voltage: DC3V-24V, optional
Vacuum pump: flow rate: 0.2-70L/min, maximum negative pressure: 30-98kPa, voltage: DC1.5V-24V, optional

Model	Ultimate vacuum kPa	Flow L/min	Max. Pressure Bar	Power W	DC motor V	Dimensions mm	Weight g
7V12B60R5 2	83	40	6	50	6/9/12/24	110/89/43	575
7V12C55R5 2	80	35	5.5	45	6/9/12/24	110/89/43	575
7V12D50R3 8	80	30	5	30	6/9/12/24	110/89/43	575
7V12H40R2 9	75	20	4	25	6/9/12/24	110/89/43	575

They are available with options for application requirements related to size, motor, control, voltage, chemical resistance, safety, vibration, noise and temperature resistance. All pump types offer oil-free operation.

Product Features

Optimized pump body to ensure small volume, provide large flow and maintain relatively low power consumption. The gas flow is stable and the motor runs in a wide range.

- High performance

- Dc brushed motor with 2000hours lifetime

- Dc brushless motor with >10000hours

- Imported ball bearing material design

- Professional seal design ensures low leakage rate

- Pollution-free sample gas

- High quality imported EPDM and PTFE/FKM

- Rubber materials, withstand a variety of gas corrosion
