Customizable content

Air pump: flow rate: 0.2-90L/min, maximum pressure: 0.5-12bar, voltage: DC1.5-24V, optional
Water Pump: flow rate: 0.2-5L/min, maximum pressure: 4-30bar, voltage: DC3V-24V, optional
Vacuum pump: flow rate: 0.2-70L/min, maximum negative pressure: 30-98kPa, voltage: DC1.5V-24V, optional

Model	Ultimate vacuum kPa	Flow L/min	Max. Pressure Bar	Power W	DC motor V	Dimensions mm	Weight g
4VB12A80R48B	80	16	2.6	12	6/9/12/24	102/66/40	298
4VB12B80R37B	80	12	2.5	10	6/9/12/24	102/66/40	298
4VB12C75R29B	75	10	2	8	6/9/12/24	102/66/40	298
4VB12D75R29B	70	8	1.6	7	6/9/12/24	102/66/40	298

They are available with options for application requirements related to size, motor, control, voltage, chemical resistance, safety, vibration, noise and temperature resistance. All pump types offer oil-free operation.

Product Features

Optimized pump body to ensure small volume, provide large flow and maintain relatively low power consumption. The gas flow is stable and the motor runs in a wide range.

- High performance

- Dc brushed motor with 2000hours lifetime

- Dc brushless motor with >10000hours

- Imported ball bearing material design

- Professional seal design ensures low leakage rate

- Pollution-free sample gas

- High quality imported EPDM and PTFE/FKM

- Rubber materials, withstand a variety of gas corrosion

Mini air pumps are versatile, portable devices designed for convenient inflation on the go. Powered by USB, batteries, or 12V car sockets, their compact size makes them ideal for inflating a wide range of items. Key applications include quickly topping up bicycle and scooter tires, inflating air mattresses and camping gear, preparing sports balls (footballs, basketballs), filling small pool toys, and adjusting inflatable travel pillows. They offer an essential solution for emergencies, travel, outdoor activities, and home use, eliminating the need for bulky pumps or manual effort. Lightweight and easy to store, mini pumps are a practical tool for maintaining optimal pressure in various inflatables.
